Canon CR-N500 Professional 4K NDI PTZ Camera with 15x Zoom



Key Features:

• 1" CMOS Sensor with Dual-Pixel AF
• Capture up to UHD 4K30 / 1080p60 Video
• HDMI, 3G-SDI & IP Video Output
• Built-In NDI|HX Support, 15x Zoom, PoE+
• Built-In ND Filters: 1/4, 1/16, 1/64
• Genlock, Dual XLR & 3.5 Audio Input
• Canon DIG!C DV6 Processor, 1.5 Lux
• IP, RS-422, IR, and Wi-Fi Control
• Works with Canon Control Software
• Compatible with Canon PTZ Controller

If you're working on a field or studio production with high-end cameras that can benefit from remotely controlled cameras with minimal operating crew, and you need more accurate camera-matching than a traditional PTZ camera, the satin black CR-N500 Professional 4K NDI PTZ Camera with 15x Zoom from Canon will fit right into your documentary shoot, event, streaming broadcast, reality show, or digital film production. The CR-N500 is designed to fit right into an existing multi-camera shoot, matching the color depth and visual look with its professional sensor and features so that postproduction camera matching and color correction is made easy.

The CR-N500 sports many resources of a high-resolution Canon camera or camcorder with features such as a 1" dual-pixel CMOS sensor, the Canon DIG!C DV6 image processor, scene modes, face-tracking, 15x zoom, 20x digital zoom, dual XLR / 3.5mm microphone input, and video recording up to UHD 4K. The camera also includes NDI|HX support without requiring a separate license, allowing you to drop the camera into your existing NDI network with minimal configuration. Other professional camera attributes of the N500 include genlock support, Canon Log 3 support, and built-in ND filters with clear, 1/4, 1/16, and 1/64 options.

Where the PTZ camera diverges from the Canon camcorders is in its remote options such as control via IP, RS-422 serial, IR, or Wi-Fi as well as HDMI or 3G-SDI video output. It can perform smooth, precision pan, tilt, and zoom movements with a speed range of 0.2 to 300° per second. Mic-level audio can be input via dual XLR inputs or via a 3.5mm mini-jack, and then embedded in the HDMI and 3G-SDI outputs, in your NDI|HX stream, or in RTP/RTMP/RTSP streaming output.

The camera can also be powered using PoE+ (Power-over-Ethernet) using its LAN port, so it can fit right into your existing PoE+ network without requiring the use of local power to save cabling. The camera supports  wide dynamic range, minimum brightness of 1.5 lux, and its lens features a 35mm equivalent focal length of 25.5 to 382.5mm. The camera can utilize an external controller via RS-422 or Canon's proprietary XC IP protocol on a private, secure LAN, using the optional RC-IP100 PTZ controller. Or if you'd prefer to use Canon's camera control software, the free-to-download application can work on Windows OS, so you can control all the camera functions from a laptop or tablet. The software provides a 9x9 live view, control of up to 100 cameras, settings loading and configuration, and tally functions.

Technical Specifications:

Image Sensor	1"-Type CMOS
Sensor Resolution	Actual: 13.4 Megapixel Effective: 8.29 Megapixel (3840 x 2160)
IR Cut Filter	No
Built-In ND Filter	Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters
Image Stabilization	Optical in Integrated Lens
Focus Control	Autofocus Manual Focus
Shutter Type	Electronic Rolling Shutter
Shutter Speed	1/2000 to 1/3 Second
Gain	6 to 33 dB
Minimum Illumination	1.5 Lux at 1/30 Shutter Speed
Flip / Mirror Support	Image Flip, Mirror (Vertical)
White Balance	2000 to 15,000K Presets: AWB, Manual, Set A, Set B
Focal Length	8.3 to 124.5mm (35mm Equivalent: 25.5 to 382.5mm)
Optical Zoom Ratio	15x
Max Digital Zoom	20x
Field of View	Horizontal: 73 to 5.7° Vertical: 45.2 to 3.2°
Maximum Aperture	f/2.8 to 4.5
Minimum Focus Distance	Wide: 0.4" / 1.0 cm Telephoto: 23.6" / 60.0 cm
External Recording Modes	4:2:2 10-Bit via HDMI 3840 x 2160 at 23.98/25/29.97 fps 1920 x 1080p at 23.98/25/29.97/50/59.94 fps 1920 x 1080i at 50/59.94 fps 1280 x 720 at 50/59.94 fps 4:2:2 10-Bit via SDI/BNC 1920 x 1080p at 23.98/25/29.97/50/59.94 fps 1920 x 1080i at 50/59.94 fps 1280 x 720 at 50/59.94 fps 4:2:0 8-Bit via RJ45 3840 x 2160 at 5/14.99/29.97 fps 1920 x 1080p at 5/14.99/29.97/59.94 fps 1280 x 720 at 5/14.99/29.97/59.94 fps 640 x 360 at 5/14.99/29.97/59.94 fps
Embedded Audio	SDI
Broadcast Output	NTSC/PAL
Gamma Curve	Canon Log 3, Rec709, Standard, Wide DR
IP Streaming	H.264, H.265, NDI|HX, RTMP, RTP, RTSP 3840 x 2160 at 5.00p, 14.99p, 29.97p 1920 x 1080 at 5.00p, 14.99p, 29.97p, 59.94p 1280 x 720 at 5.00p, 14.99p, 29.97p, 59.94p 640 x 360 at 5.00p, 14.99p, 29.97p, 59.94p
IP Multi-Stream Support	Simultaneous H.264: UHD 4K, 1080p, 720p, 360p
Presets	100 via IP, VISCA
Move Speed	Pan: 0.1 to 100°/sec Tilt: 0.21 to 100°/sec
Movement Range	Pan: 340° (-170 to 170°) Tilt: 130° (-30 to 90°)
Tally Light	Yes
Supported Control Protocols	Canon XC IR RS-422 VISCA
Video I/O	1x BNC (3G-SDI) Output 1x HDMI (Unspecified Signal) Output 1x RJ45 (NDI) Output
Audio I/O	2x XLR 3-Pin Microphone Input 1x 1/8" / 3.5 mm TRS Stereo Microphone Input
Other I/O	1x RJ45 (RS-422, VISCA) Input 1x USB-A Input 1x BNC (Genlock) Input/Output
PoE Support	PoE+ 802.3at
Power I/O	1x Barrel (24VDC) Input
Power Consumption	PoE: 19.6 W Power Supply: 24 VDC 18.6 W
Operating Temperature	32 to 104°F / 0 to 40°C
Storage Temperature	32 to 104°F / 0 to 40°C
Operating Humidity	10 to 90%
Storage Humidity	10 to 90%
OS Compatibility	macOS 11 Windows 10 (64-Bit Only)
Mobile App Compatible	Yes: Android & iOS Functionality: Adjust Settings, Remote Control, Setup
Dimensions (W x H x D)	7.87 x 10.59 x 8.19" / 19.99 x 26.9 x 20.8 cm (Without Protrusions)
Weight	9 lb / 4.1 kg (Body Only)

In the Box:

• Canon CR-N500 Professional 4K NDI PTZ Camera with 15x Zoom (Black)
• IR Remote Control
• Remote Battery
• Safety Wire
• Safety Wire with Screw
• Ceiling Plate
• AC Adapter
• Power Cable
• Limited 3-Year Manufacturer Warranty
