Blackmagic Mini Converter SDI to HDMI 6G

Blackmagic Design

Blackmagic Mini Converter SDI to HDMI 6G

3 years warranty
Genuine product
Secure payment

3 years warranty from the manufacturer.

Key Features:

2 x 4K SDI Input
1 x HDMI Type A and 1 x SDI Output
Supports SD, HD, UHD 4K & DCI 4K Signals
Automatic Input Signal Detection
24-Bit, 48 kHz Audio
Analog & AES-EBU Digital Audio Outputs
De-Embeds Audio from SDI
Settings via Mini Switches or Software
USB 2.0 Port for Firmware Updates
12V Universal Power Supply Included

The Blackmagic Design SDI to HDMI 6G Mini Converter converts SDI in resolutions up to DCI 4K (4096 x 2160) at 24p and UHD 4K (3840 x 2160) up to 60p to HDMI. This is useful for connecting consumer devices that require HDMI signals with professional SDI video equipment. With a compact form factor and easy-to-use controls, the Mini Converter is ideal for a variety of broadcast, post production, and professional AV applications.

Using 4K HDMI and 6G-SDI technologies, the Mini Converter automatically detects the input video format and instantly changes between SD, HD, and UHD/DCI 4K formats. Featuring two SDI inputs, and both an SDI and HDMI output, the unit will automatically switch from the main SDI input to the alternate input if the main input fails. Audio is de-embedded from the SDI input and available in the HDMI output as well as the AES/EBU or analog audio output.

The Mini Converter's settings are controlled using the built-in switches or via USB using the control software for Max OS X or Windows computers, which can be downloaded on Blackmagic Design's website. The USB port also enables the firmware to be updated.

The device is powered by an included 12V power supply and includes international socket adapters.

Additional Features:

4:2:2 Sampling and color precision
HD scaler and SD down-conversion
24-bit, 48 kHz audio sampling
Compliant with SMPTE 259M, 292M, 296M, 372M, 424M, 425M Level A/B, and SMPTE ST-2081 standards
Down-conversion for monitoring Ultra HD on HD monitors
Built-in 3D LUTs
HDMI instant lock for instant video display when an SDI input is connected

Technical Specifications:

Video Input	2 x 6G-SDI
Video Output	1 x HDMI type A 1 x 6G-SDI
Multi-Rate Support	Auto detection of SD, HD, or 4K signals
Reclocking	Yes
Audio Output	Analog: 2 channels with 1 x 1/4" jack per channel AES/EBU: 4 channels with 1 x 1/4" jack
Format Support	DCI 4K 24p UHD 4K 3840 x 2160p: 30/29.97/25/24/23.98 HD 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 SD NTSC: 525i/59.94 PAL: 625i/50
SDI Compliance	SMPTE 259M/292M/296M/372M/424M/425M Level A or Level B/SMPTE ST-2081
SDI Video Rates	SDI video connections are switchable between standard definition, high definition, Level A or Level B 3G-SDI and 6G-SDI.
SDI Video Sampling	4:2:2 4:4:4
SDI Color Precision	4:2:2 4:4:4
SDI Color Space	YUV RGB
SDI Audio Sampling	24-bit, 48 kHz
SDI Auto Switching	Automatically detects SD, HD, or 6G-SDI
HDMI Format Support	UHD 4K 3840 x 2160p: 30/29.97/25/24/23.98 HD 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50 SD NTSC: 525i/59.94 PAL: 625i/50
HDMI Color Space	YUV and RGB
HDMI Color Precision	4:2:2 4:4:4
Format Conversion	HD down-conversion
Settings Control	Mini switches or USB software
Firmware Upgradeable	Via USB
Power Supply	12 VDC
Power Consumption	5.2 W
Operational Voltage Range	12 to 31 VDC
Operating Temperature	32 to 104°F / 0 to 40 °C
Storage Temperature	-4 to 113°F / -20 to 45 °C
Relative Humidity	0 to 90% non-condensing
Dimensions	4.49 x 3.63 x 0.90" / 11.40 x 9.22 x 2.29 cm
Weight	9.06 oz / 256.85 g

In the Box:

Blackmagic Design SDI to HDMI 6G Mini Converter
12V Power Supply
Limited 3-Year Warranty
